2.5G-SFP-SX-850nm-500M
2.67Gb/s data transmission speed, VCSEL laser transmitter and PIN photodetector, 55/62.5 μ m single-mode fiber transmission up to 550m, hot-swappable SFP interface, LC/UPC pluggable optical interface, low power consumption, metal housing for reducing electromagnetic interference, ROSA lead-free standard, single +3.3V power supply, support digital diagnostic monitoring function, SFF-8472 protocol
| Compatible Model Name | SFP-2.5G-MM | Vendor Name | CFTX |
| Form Factor | SFP | Data Rate | 1000Mbps |
| Wavelength | 850nm | Max Transmission Distance | 550m |
| Connector | Duplex-LC | Media | Multimode-SMF |
| Transmitter power | -9~0dBm | Receiver sensitivity | <-17dBm |
| DDM/DOM | Yes | Temperature Range | 0~70°C（Commercial grade） /-40~85°C（Industrial grade） |
| Protocols | Fast Ethernet, Gigabit Fibre Channel, MSA | Laser Type | VCSEL |
| Compatible Brands | (Cisco)、Arista 、HUAWEI、ZTE、DLL、Intel、H3C、RuiJie、IBM、HP…… |
