25G-SFP28-SR-850nm-100m

25.78Gb/s data transmission speed, DFB laser transmitter and PIN photodetector, 9/125 μ m single-mode fiber transmission up to 10km, hot-swappable SFP interface, LC/UPC pluggable optical interface, low power consumption, metal housing for reducing electromagnetic interference, ROSA lead-free standard, single +3.3V power supply, support digital diagnostic monitoring function, SFF-8472 protocol

产品详情
资料下载

Compatible Model Name	SFP-25G-SR	Vendor Name	CFTX
Form Factor	SFP28	Data Rate	25.78Gbps
Wavelength	850nm	Max Transmission Distance	10km
Connector	Duplex-LC	Media	Multimode-SMF
Laser Type	VCSEL	Receiver	PIN
DDM/DOM	Yes	Temperature Range	0~70°C （Commercial grade） -40~85℃（Industrial grade）
Transmitter power	-5~2.4dBm	Receiver sensitivity	<-10.3dBm
Power Consumption	1W	Extinction ratio	＞2dB
Modulation	NRZ	CDR	TX&RX
Transmission dispersion	1dB	Power Budget	5.3dB
Packaging Technology	TO	FEC Function	RS-FEC,FC FEC
Protocols	IEE 802.3by,FP28 MSA,SFF-8472,SFF-8432,CPRI,ECPRI	Apply	25GBASE Ethernet, Data Center, Telecom
Receive overload	2.4dBm	EMC	yes

Compatible Brands

(Cisco)、Arista 、HUAWEI、ZTE、DLL、Intel、H3C、RuiJie、IBM、HP……
